• No. of Positions:48
• AWG:14-20
• Amperage:13
• IP Rating:IP67 (in mated condition)
• Contact Size:16
• Contact type (Pin/Socket):Pin
• Contact Material:Copper Alloy
• Plating:Gold
• Contacts Included:Yes
• Housing Material:Thermoplastic
• Color:Black
• Operating Temperature:-55°C TO +125°C
• Dielectric Value:Dielectric withstanding voltage less than 2 milliamps current leakage @ 1500 volts AC
• 1005 megohms at 25°C
• Mating Cycle Durability:> 100
• Mating Part(s):AT06-12SX-*(X = A,B,C,D KEYS ; * = ALL MODIFICATIONS),AIPXE-5X650A-xxxx AND AIPXE-5X650B-xxxx ENCLOSURE
